5554-8204 - IBM i Model E8A Mirror 35GB Disk/Controller Pkg

IBM i Power 6, 8204 (#5554) Mirror 35GB Disk/Controller Pkg

This feature provides a disk unit controller IBM i Power 6, 8204 (#2780 equivalent) and twelve (12) 15k rpm 35GB disk units IBM i Power 6, 8204 (#4326 equivalent) for servers doing mirroring. Either #0042 Mirrored System IOP Level or #0043 Mirrored System Bus Level is a prerequisite.

Attributes provided: Twelve (12) 35GB mirrored disk units

Attributes required: PCI slot for disk controller, 12 disk unit slots and #0042 or #0043.

For 8204-E8A: IBM i Power 6, 8204 (#5554)

Minimum required: 0

Maximum allowed: 45 (Initial order maximum: 0)

OS level required: IBM i V5R4 with V5R4M5 Machine Code, or later.

Initial Order/MES/Both/Supported: Supported

CSU: Yes

Return parts MES: Does not apply
