3670-8203 - IBM Power6 E4A SAS Cable, DASD Backplane (Split-8203

The IBM Power6 8203-E4A (#3670) SAS Cable, DASD Backplane (Split) to Rear Bulkhead

The SAS cable connects the DASD Backplane with External SAS Port The IBM Power6 8203-E4A (#8345/#8346/#8310) to the rear bulkhead of the system providing connection via cable #3679 to a slot adapter SAS controller. This feature gives the user the ability to split the backplane, allocating a SAS controller for each half of the internal disks.

Attributes provided: Cable

Attributes required: DASD Backplane with External SAS Port The IBM Power6 8203-E4A (#8345/#8346/#8310), SAS Cable (AI) - 1M The IBM Power6 8203-E4A (#3679), and one of the following SAS controllers: #5900, #5901 or #5912

For 8203-E4A: The IBM Power6 8203-E4A (#3670)

Minimum required: 0

Maximum allowed: 1 (Initial order maximum: 1)

OS level required: None

Initial Order/MES/Both/Supported: Both

CSU: Yes

Return parts MES: No
