iSCSI SAN

iSCSI SAN Storage devices by Cybernetics provide up to 700,000 IOPS performance and 1.5 GB/s transfer rates, providing best in class SAN Storage device options in comparison to Dell EqualLogic, EMC & NetApp Storage. iSAN SSD SAN Storage Arrays provide up to 1,000,000 IOPS and 4 GB/s Transfer Rates. The iSAN iSCSI SAN Storage line uses a unique modular design allowing dual controller devices to be upgraded to higher models without any downtime, reconfiguration or disruption of data stores. Capacity of Cybernetics iSCSI SAN Storage devices can be increased within the same chassis by simply adding disk drives (SAS, SATA, SSD or mix) or additional expansion SAN Storage arrays (without downtime). iSAN Storage devices can scale to over 1PB. Cybernetics entry iSCSI SAN device (1000 series) provides up to 100,000 IOPS with 192TB max capacity and its fastest Enterprise iSCSI SAN (7000 series) provides up to 700,000 IOPS series. All Cybernetics iSCSI SAN storage devices offer both 100% SSD SAN or Hybrid SAS, SATA or MIX Storage solutions.
Enterprises with greater data access demands will likely want a pure SSD SAN series with up to 1,000,000 IOPS performance and 4 GB/s transfer rates: 6140 (Brochure), 6520 (Brochure), 4520 (Brochure) & 2520 (Brochure).
iSCSI SAN Storage, Cybernetics iSAN Comparison Chart
iSAN Series
|
1000 Series | 3000 Series | 4000 Series | 5000 Series | 6000 Series | 7000 Series |
Capacity | 64 TB | 64 TB | 96 TB | 64 TB | 96 TB | 64 TB |
Capacity w/ Expansion |
192 TB via 2 Exp Units |
320 TB via 5 Exp Units |
768 TB via 6 Exp Units |
448 TB via 6 Exp Units |
448 TB via 7 Exp Units |
448 TB via 7 Exp Units |
Max Performance | 100,000 IOPS | 300,000 IOPS | 400,000 IOPS | 500,000 IOPS | 600,000 IOPS | 700,000 IOPS |
Max Transfer Rate | 200 MB/s | 500 MB/s | 1.2 GB/s | 1.2 GB/s | 1.5 GB/s | 1.5 GB/s |
Controllers | 2 | 2 | 1 | 2 | 2 | 2 |
Dedicated I/O Cache | 4GB per Controller | 12GB or 24GB Upgradeable | 24GB, 48GB or 96GB | 24GB, 48GB or 96GB | 48GB, 96GB, or 192GB | 48GB or 96GB |
Controller Upgrades | Yes | |||||
Drive Bays | 16/24 | 16/24 | 8/12/16/24 | 16/24 | 8/12/16/24 | 16/24 |
Drive Types |
1TB, 2TB, 3TB & 4TB SAS 7,200 RPM |
|||||
Mix Drive Types in Same Chassis |
Yes | |||||
1 GbE Ports | 2 per Controller +1 Admin |
4 per Controller, Upgradeable | 9 or 18 | 6 per Controller, Upgradeable | 9, Upgradeable | 6 per Controller, Upgradeable |
10 GbE Ports | Optional | |||||
Fiber Channel Support | 8Gb or 16Gb FC | |||||
miniSAS Support |
6Gb/s Included | |||||
LUNs / Volumes | No Limit | |||||
SnapShots | 256 per Volume, Unlimited Available | No Limit | ||||
SnapShot Replication | Site-to-Site Included, Multi-Site Optional |
Multi-Site Included | ||||
Deduplication | Yes | |||||
Dynamic Expansion | Yes | |||||
Backup to Portable Disk |
Yes | |||||
Backup to Tape | Yes | |||||
Redundancy Hot-Swap |
Disk Drives, Controller & Power Supply | |||||
High Availability | Dual Controller, Auto-Failover | |||||
SNMP Alerts | Yes | |||||
RAID Levels | 0, 1, 5, 6, 10 | |||||
Installation & Training Support | Included | |||||
Technical Support | Lifetime, Unlimited | |||||
Warranty | 2 Yr Parts & Labor | |||||
