6417-8203 - RIO-2 Bus Adapter

The IBM Power6 8203-E4A (#6417) RIO-2 Bus Adapter

The #6417 feature allows existing HSL and optical HSL connected towers the option of switching to copper RIO-2 connectivity. The #6417 has two RIO-2 ports and provides connectivity for #0595, #5094, and #5294 PCI expansion towers and expansion units.

Attributes provided: Two ports of RIO-2 connectivity

Attributes required: Bus adapter slot in PCI expansion tower/unit

For 8203-E4A: The IBM Power6 8203-E4A (#6417)

Minimum required: 0

Maximum allowed: 12 (Initial order maximum: 12)

OS level required: IBM i V5R4 with V5R4M5 Machine Code, or later.

Initial Order/MES/Both/Supported: Both

CSU: Yes

Return parts MES: No
