IBM 3649 is a 450GB 15K RPM SAS Disk Drive for IBM AIX and Linux Systems. The IBM 3649 Disk Drive is only available in refurbished condition, includes a 30 day warranty and eligible for new or existing IBM Maintenance Contracts. The IBM 3649 is supported on the following IBM AIX/Linux Models: E4A, E8A, EMA, 520, 550, 561, 570, MMA, 590, 595, FHA, F2A, 52A, 55A and Machine Types: 8203, 8204, 8234, 9111, 9113, 9116, 9117, 9119, 9125, 9131, 9133.  Attached SAS DASD device, in a carrier capable of providing Hot Swap support. Provides 450GB of storage capacity. Supports the industry standard SAS interface. Can be used only in a drawer/system designed to support the SAS interface.

Characteristics:

• Form Factor: 3.5 inch Form Factor, 1 inch drive.
• Cable included: No
• External Interface: standard SAS Dual Port
• Rotational Speed: 15,000 RPM
• Interface Speed: 300 MB/sec.
• Format: 512 Bytes/sector default, 528 Bytes/sector possible with re- format.
• Attributes provided: 450GB of disk storage mounted in a carrier.
• Attributes required: one SAS disk drive bay
• For 8204-E8A: (#3649)
  • Minimum required: 0
  • Maximum allowed: 582 (Initial order maximum: 250)
  • OS level required:
    • No IBM i support
    • AIX 5L for POWER version 5.3 with the 5300-09 Technology Level
    • AIX 5L for POWER version 5.3 with the 5300-06 Technology Level and Service Pack 10
    • AIX 5L for POWER version 5.3 with the 5300-07 Technology Level and Service Pack 7
    • AIX 5L for POWER version 5.3 with the 5300-08 Technology Level and Service Pack 5
    • AIX Version 6.1 with the 6100-02 Technology Level
    • AIX Version 6.1 with the 6100-00 Technology Level and Service Pack 7
    • AIX Version 6.1 with the 6100-01 Technology Level and Service Pack 3
    • SUSE Linux Enterprise Server 10 SP1 for POWER Systems or later.
    • Red Hat Enterprise LInux for POWER version 4.5 or later.
    • Red Hat Enterprise Linux for POWER version 5.1 or later
  • Initial Order/MES/Both/Supported: Both
  • CSU: Yes
  • Return parts MES: No

  Note: 582 is combined total for FC 3636, 3647, 3648 and 3649.
